Rotary dryers

Triple-drum dryer

【Effective Volume】: 16.63-81.38m³

【Capacity】:20-70t/h

【Heat Source】:Coal, oil, natural gas, timber.

【Drying Materials】:Powder, coal, sand, clay, slag, etc.

E-mail: service@tdaxy.com

get a quote online faq
Advantages:

Overview

Product Description:
Triple-drum dryer is mainly used or drying a certain humidity and size of granular materials, such as yellow sand used in dry powder and mortar, various specifications of sand used in a foundry industry, blast furnace slag used in building materials and cement industry, clay in a small size, small materials, which have no chemical changes, resists high temperature and are with flyblow dust, used in chemical industry. In accordance with the request of materials and water in different industries, water in materials which are dried can be below 1-0.5%.

Advantages of Triple-drum Dryer:

1. The needed investment is only 1/6 of foreign import product.

2. The final moisture of the materials is ensured to be below 0.5% making it the first choice of dry-mixed mortar and slag powder production line.

3. The self heat preservation heat efficiency of the cylinder can reach as high as over 70% thus improving the heat efficiency by 35%.

4. The fuel can be coal gas and oil and it can be used for drying lump granulous and powdery materials whose granularity is below 20mm.

5. Compared with monocular dryer machine its floor space is reduced by about 50% infrastructure investment reduced by about 50% and electricity consumption reduced by 60%.

6. The needed final water content index can be easily regulated according to customers’ requirement.

7. The temperature of the air out is low and the service life of the dust removing equipment is long.

8. It needs no rack wheel and pinion driving but uses riding wheel for transmission.


Products:

Triple-drum dryer is specially designed to dry materials with high viscosity like clay, gypsum and other materials. Taida triple-drum dryer, which is produced based on Germany advanced clay drying technology and has reasonable design, stable functioning, simple operation, wear resistance and durability, higher thermal efficiency and better drying effect.

Technical Parameters:
Item/Unit/Model Φ2.5×7m Φ2.7×7m Φ3.0×7.0m Φ3.2×7.0m Φ3.6×8m
Diameter of outer cylinder(m) 2.5 2.7 3.0 3.2 3.6
Length of outer cylinder(m) 7 7 7.0 7.0 8
Cylinder volume( m³ ) 16.63 16.63 52.678 52.678 81.38
Rotating speed of cylinder(rpm) 4-10 4-10 4 -10 4 -10 4 -10
Initial moisture of slag(%) 10-12 10-12 10-12 10-12 10-12
Final moisture of slag(%) 1 1 1 1 1
Initial moisture of yellow ground(%) 8-10 8-10 8-10 8-10 8-10
Final moisture of yellow ground (%) 0.5-1 0.5-1 0.5-1 0.5-1 0.5-1
Highest intake air temperature(℃) 700-750℃ 700-750℃ 700-750℃ 700-750℃ 700-750℃
Production capacity(T/h) Yellow sand25-30
       Slag20-25
Yellow sand30-35
       Slag25-30
Yellow sand35-40
       Slag30-35
Yellow sand45-50
       Slag35-40
Yellow sand65-70
       Slag60-65
Motor type Y2-132m-4E Y2-132m-4E Y2-160m-4 Y2-160m-4 Y2-160m-4
Motor power(kw) 7.5×2 11×2 7.5×4 7.5×4 15×4
Reducer type XWD7-23-11W XWD7-23-11W XWD6-23-7.5KW XWD6-23-7.5KW XWD8-23-15KW
Velocity ratio of reducer 29 29 29 29 29

Note: No further notice if the technical parameters change.
