Rotary dryers

Industrial Dryer

【Capacity】: 2.5-36t/h

【Power】:7.5-75KW

【Heat Source】:Coal, oil, natural gas, timber.

【Drying Materials】:Sawdust , palm shell, wood chips, bagasse, straw, vinasse , slag, coal powder, mining powder, clay, sand, limestone and so on.

E-mail: service@tdaxy.com

get a quote online faq
Advantages:

 Industrial drying machine is widely used in such industries as fodder, chemistry, medicine and mine. The working process of industrial dryer machine goes like this: the moist materials whose water has been drained go into the dryer machine, under the rotation of the lifting board evenly installed inside the roller drum, the materials will be evenly scattered inside the drying machine and carry out sufficient contact with the hot air, thus accelerating the heat transfer and mass transfer. In the drying process, under the lifting board with a certain inclination and the heat media, the materials will move to the lower end of the dyer machine and be discharged. Industrial dryer for sale is suitable for drying residue materials whose water content is below 85% such as brewer’s grain, bean dregs, guniting corn bran, slurry and pomace, so that it has excellent effect for opening up fodder resources, reducing the feeding cost and reduce environment pollution.
Features:
1.The rotary drum is made of stainless steel with smooth and beauty appearance, durable in use, and no harm to the fabric.
2. Wide open gate design with 180 degree free open makes it easy to fetch the clothes.
3. It is transmitted by texrope with stable operation, and low noise. It is safe and reliable.


Products:

Industrial dryer also can be called rotary dryer or rotary drum dryer. It is widely used in food, forage, chemical engineer, medicine, and mining industries.  TAIDA series of dryer go for the drying of slag with moisture less than 85%, such as brewer’s grains, bean dregs, sprayed concrete corn husk, coal slurry, and fruit residues. It has favorable effects on opening up feeding stuff, lowering the feed cost, and reducing the environmental pollution.


Technical Parameters:
 model(m)
(shell diameter*shell length)
Shell cubage
(m³)
Capacity
(t/h)
Gradient
(°)
Highest inlet air
temperature
(℃)
Main motor
power
(kw)
Weight
(t)
Φ1.2×8.0
9.0
1.9~2.4
3~5
700~800
7.5
9
Φ1.2×10
11.3
2.4~3.0
3~5
700~800
7.5
11
Φ1.5×12
21.2
4.5~5.7
3~5
700~800
15
18.5
Φ1.5×14
24.7
5.3~6.6
3~5
700~800
15
19.7
Φ1.5×15
26.5
5.7~7.1
3~5
700~800
15
20.5
Φ1.8×12
30.5
6.5~8.1
3~5
700~800
18.5
21.5
Φ1.8×14
35.6
7.6~9.5
3~5
700~800
18.5
23
Φ2.2×12
45.6
9.7~12.2
3~5
700~800
22
33.5
Φ2.2×14
53.2
11.4~14.2
3~5
700~800
22
36
Φ2.2×16
60.8
13.0~16.2
3~5
700~800
22
38
Φ2.4×14
63.3
13.5~16.9
3~5
700~800
37
45
Φ2.4×18
81.4
17.4~21.7
3~5
700~800
37
49
Φ2.4×20
90.4
19.3~24.1
3~5
700~800
45
54
Φ2.4×22
99.5
21.2~26.5
3~5
700~800
45
58
Φ2.6×24
127.4
27.4~34.0
3~5
700~800
55
73
Φ3.0×20
141.3
30.1~37.7
3~5
700~800
75
85
Φ3.0×25
176.6
37.7~47.1
3~5
700~800
75
95
Φ3.2×25
201
42.9~53.6
3~5
700~800
90
110
Φ3.6×28
285
60.8~76.0
3~5
700~800
160
135

Note: No further notice if the technical parameters change.
