Rotary dryers

Intermittent Ball Mill

【Effective Volume】: 0.23-150m³

【Power】:1.5-315KW

【Features】:Wide application range, simple structure and low cost.

【Application】:Suitable for grinding operation with small size requirements and small production capacity requirements.

E-mail: service@tdaxy.com

get a quote online faq
Advantages:

Ball mill  is widely used in powder-making production line including cement silicate new-type building material refractory material fertilizer ore dressing of ferrous metal and non-ferrous metal glass ceramics etc.

1. Compatible with various materials wide application scope;
2. Simple structure lower cost and small investment and it saves more energy and electricity compared with similar products;
3. Prevent dust leakage for it’s good sealed performance;
4. Uniform product size simple operationreliable performance and can be used safely.

Products:

Intermittent ball mill is mainly used in materials mixing and grinding.  It can be used not only in dry type grinding, but also be used in wet type.  It can control the grinding time according to the requirement of the grinding size, and also it can adopt different liner type according to production requirement.  It is suitable for grinding operation with small size requirements and small production capacity requirements.

Technical Parameters:
Model Effective volume(m3) Rotary speed(r/min) Feeding quantity(t) Power(kW) Weight /without liner(t)
φ600×840 0.23 55 0.1 1.5 1.35
φ800×940 0.47 40 0.2 2.2 1.42
φ950×1020 0.72 34 0.3 3 1.5
φ1200×1400 1.58 34 0.5 4 2.5
φ1450×1760 2.91 26.5 1 11 3.5
φ1800×2100 5.3 23 1.5 15 4.5
φ2000×2300 7.2 16 2 22 5.9
φ2240×2600 10 18.7 3 30 7.4
φ2450×2800 13 16 4 37 9.5
φ2700×2900 16.6 16 5 37 10.5
φ2800×3100 19 15 6 45 12.4
φ2850×4000 25.5 14 8 55 16
φ3000×4650 32.5 16 14 90 20.8
φ3200×4650 37.5 16 18 90 23
φ3400×4650 43 12.5 23 90 25
φ3400×6300 57 12.5 30 110 30
φ3600×6300 64 11.8 36 110 32
φ3600×6500 66 11.8 38 110 32
φ3600×6700 68 11.8 40 132 35
φ3600×7170 68 11.8 40 110 35
φ4000×7860 99 10 60 185 48
φ4100×11200 147 10 100 315 73

Note: No further notice if the technical parameters change.
