Rotary dryers

Water-cooling Ball Mill

【Effective Volume】: 3-43m³

【Power】:37-1000KW

【Weight】:13-200t

【Processible Materials】:Aluminium, magnesium powder, sulphur and chemical raw material.

E-mail: service@tdaxy.com

get a quote online faq
Advantages:

1. Strong adaptability to the raw material large capacity of production;
2. Prevent dust leakage for it’s good sealed performance;
3. Sealed feeding water cooling inert gas protection to ensure the equipment be safely used.

Products:

TD series water-cooling type anti-explosion ball mill uses circulating water cooling and inert gas to fill the mill.  It is indispensable equipment for inflammable, explosive, vulnerable to physical and chemical reaction material grinding operation, and widely used in grinding operation of aluminium, magnesium powder, sulphur and chemical raw material.

Technical Parameters:
Model Effective volume(m3) Max ball load(t) Power(kW) Weight(t)
φ1200×3000 3 5.7 37 13
φ1500×4500 7.1 14 115 20
φ1830×4500 10.6 21 155 32
φ2100×4500 14.1 28 245 52
φ2200×4500 15.6 31 245 54
φ2400×4500 18.7 36 320 71
φ2700×4500 23.5 46 450 90
φ3200×4500 33.5 66 800 137
φ3600×4500 42.8 84 1000 200

Note: No further notice if the technical parameters change.
